Specialty Dosimeter
Environmental dosimeters are well-suited to monitor low-level photon radiation and withstand the most intense environmental situations.
4-Element TLD: 1 LiBO:Mn (TLD800) and 3 CaSO:Dy (TLD900)
This dosimeter is designed for outdoor applications and may be used to measure radiation for site characterization, at site boundaries for regulatory compliance, and to monitor public exposure. Our issued reports make it easy to compare to ion chamber results.
Technical Specifications |
|
Environment 814 |
|
Description |
4-element TLD (1LiBO:Mn [TLD800] and 3 CaSO:Dy [TLD900] elements) |
Badge Type |
20 = Environmental 814* |
Holder Type |
CA, HA, SA |
Accreditations |
ANSI N545-1975 |
Minimum Reportable Dose |
— |
Useful Dose Range |
5 mrad (0.05 mGy) - 500 rad (5 Gy) |
Energy Response |
Photon 40 keV - 6 MeV |
* Not accredited for personnel monitoring |
|
